500512: Send one HDMI audio/video signal to eight screens at 8K

The HDMI 2.1 48Gbps 1x8 splitter (model: 500512) is a versatile device with various applications, offering advanced features for splitting HDMI signals from one source to eight displays.

The HDMI 2.1 48Gbps 1x8 splitter's ability to handle high data rates, support 8K resolution, and provide features like EDID management and cable equalization makes it suitable for a wide range of applications in both residential and commercial settings.

Typical Applications
• Home entertainment systems
• Gaming setups
• Professional AV installations
• Digital signage
• Educational institutions
• Medical imaging
• Broadcasting and production
• Compatibility testing
• Event venues

Features and Benefits
• HDMI 2.1 support
• HDCP 2.3 compliant
• Supports 48Gbps FRL and 18Gbps TMDS video bandwidth
• Supports video resolution up to 8K/60Hz 4:2:0 12-bit, 4K/120Hz 4:4:4 12-bit
• HDMI 2.1 protocols: VRR, ALLM, QMS, QFT, SBTM
• Support HDR, HDR 10, HDR 10+, Dolby Vision, HLG pass-through
• LPCM 7.1CH, Dolby TrueHD, Atmos and DTS-HDMaster, DTS:X Audio pass-through
• 8K to 4K or 8K/4K to 1080p auto down scaling on all outputs
• HDR to SDR auto converting on all outputs
• Advanced EDID management
• Compact design for easy and flexible installation

Package Content
1x HDMI 2.1 48Gbps 1x8 Splitter
1x Power Supply
Cables are not included

Required Cables (for host connection)
1x HDMI
